GB/T16491-1996 Microcomputer Economical Materials Testing Machine
Equipment Overview
ZL-8003A Microcomputer Economical Materials Testing Machine combines electronic technology with mechanical transmission for precise load speed control and force measurement. Featuring high accuracy and sensitivity for load and displacement measurement, this machine offers simple operation and compact design that allows direct placement on testing tables. Ideal for quality control in production lines, it's designed for testing both metallic and non-metallic materials with loads under 5KN.
Download Technical Documentation Testing Capabilities
This machine performs comprehensive material testing including tensile, compression, bending, shear, peel, tear, and two-point extension tests (with extensometer). Suitable for quality control of textiles, rubber, plastics, synthetic leather, tape, adhesives, plastic film, composites, electronics, metals, and various other materials.
Key Features
- Electrostatic spray finish for elegant appearance with multifunctional and economical design
- Clear LCD digital force display with tension/compression discernibility
- Multiple unit options: N, Kg, Lb, Ton with automatic conversion
- Backlit LCD for operation in low-light environments
- Single measurement recording for maximum tension and compression forces with automatic/manual zeroing
- Automatic shutdown system for overload protection
- Single-column structure offering sophisticated and economical design
Industry Applications
Widely used in wire and cable, hardware, electronic equipment, packaging, printing, medical devices, auto parts, textiles, leather, apparel, footwear, rubber and plastic products, universities, research laboratories, inspection arbitration, technical supervision departments, and various other industries. Essential equipment for quality management and physical testing.
Technical Specifications
| Maximum Load | 5KN |
| Maximum Stroke | 800mm |
| Pillar Length | 1000mm |
| Test Speed Range | 0.001～500mm/min |
| Dimensions (H*W*D) | 450*550*1400mm |
| Weight | Approximately 150kg |
| Power Supply | AC 220V |
Standard Configuration
Includes one set of tensile fixtures
